优势概述
TSR-6 控制和保护继电器；
重载设计，环境温度达 60°C；
完善的保护包；
通讯：Modbus, Profibus, Devicenet；
用户友好，易于设置和操作；
先进的电子式电压互感器 EPT；
故障显示，各相分别显示；
频率在40-70Hz波动的不稳定系统。
设计标准
IEC 62271-200 High Voltage switchgear and control gear.
IEC 60061-1 High Voltage test techniques,General definitions and test requirements.
IEC 60694 Common specifications for high voltage switchgear and control gear standard.
IEC 71-1 Insulation co- ordination
IEC 71-2 Insulation co- ordination.
EN 50178:1998 Electronic equipment for use in power installation.
IEC 664 Insulated coordination within low- voltage systems and including clearances and creepage distances for equipment.
IEC 60470, UL 347 Vacuum contactors.
IEC 282-1 Vacuum contactors
DIN 46234 Cable lugs
DIN 0472+IEC 754 Medium voltage cables
EN 61000-6-2 / 4 Electromagnetic compatibility (EMC)- Immunity/(EMC)- Emission
EEC/72/23 Electrical safety-Council Directive
标准变压器和特种变压器
标准变压器 Standard: Oil, Dry, Molded, etc.
特种变压器 Special: Multi-pole and phase shifting
范围 Ratings: Maximum Ratings 30MVA, 15kV
温度范围 Temperature: Operating -10° to 60°C; Storage -20° to 70°C
电气安全委员会指引 Electrical safety-Council Directive (EC)
